How many pumps does it support and how should they be wired?

Up to three, with hoses included for three and a 6-pin connector that lets each pump be wired individually. They should be staged — the car should start, idle and cruise on one pump, with the others coming on only as demand requires.

What outlet and return sizes are available?

Configurable output and return in 6, 8 or 10AN, with a 10AN outlet port and a 3-to-1 fuel merge fitting.

Do the dust seals go inside the fuel tank?

No. They are for the outer connector only and are neither fuel safe nor watertight.

Is it E85 compatible?

Yes — ethanol compliant, Type II hard anodized, with PTFE fuel lines.

Does it retain the factory fuel level sensor?

Yes, mounting provisions for the factory sensor are included.

Is the relay harness specific to my car?

No. The same relay harness is used across every ASE pump hanger.

Autosports Engineering Toyota Supra MK4 MKIV Triple Fuel Pump Hanger

Description
Shipping + Returns

Description

This is our Toyota Supra MKIV MK4 fuel pump hanger system.

Features:

Billet 6061-T6 Aluminum
Configurable Output 6/8/10AN
Configurable Return Fitting Size 6/8/10AN
6-Pin Connector for individual wiring of up to 3 fuel pumps
Ethanol Compliant
Type II hard anodized to prevent corrosion
PTFE Fuel Lines
Harness Kit for in car connections
Hoses included for 3 Pumps
10AN Outlet Port
3-1 Fuel Merge Fitting
Factory Fuel level Sensor Mounting provisions

How the pumps should be wired

The 6-pin connector allows each pump to be wired individually so they can be staged. The car should start, idle and cruise on a single pump, with the second and third coming on only as demand requires. Running all three continuously heats the fuel and shortens pump life.

Relay harness

The ASE relay harness is not application specific — the same harness is used across every ASE pump hanger.

Seals

Supplied dust seals are for the outer connector only — not fuel safe, not watertight, and not used inside the tank.
